（Customized） Air-cooled Hydrogen Fuel Cell System

AS200/400/1000/2000/3000/5000

Made by China Hycircle technology co., LTD., air cooled hydrogen fuel cell system is famous for its durability, has high power characteristics, and can run steadily in low temperature environment, start quickly, short response time, through the use of hydrogen fuel and oxygen in the air reaction, efficient output clean electricity, only produce water vapor as a by-product. This system applies new energy vehicles, distributed power generation, portable power generation and other industries and markets, and the power of the product ranges from a few watts to a few kilowatts, which is favored because of its wide applicability and market compatibility.

Quantity

Contact Now

add to cart

The air-cooled hydrogen fuel cell system made by China Hycircle Technology Co., Ltd. uses air as a coolant and uses hydrogen and oxygen to react chemically on the electrode to generate electricity and water. Mainly consists of fuel cell stack, hydrogen supply system, air supply system, thermal management system, etc., with high efficiency, environmental protection, compact structure, the characteristics of strong environment adaptability, compared with the liquid cooling battery system, air cooling system reduces the peripheral equipment, manufacturing cost and maintenance cost are low, the overall more light and flexible, especially in high altitude or low temperature area, air cooling system does not need to keep the coolant circulation stability, have stronger adaptability. The product is widely used in small vehicles, low-power backup power supply and long-endurance drones and other fields. With the support of global environmental protection policies, hydrogen energy is an important element to promote the development of green energy.

Hydrogen Fuel cell System( Air-cooled )200W-5KW
Model	AS200	AS400	AS1000	AS2000	AS3000	AS5000
Rated Power(W)	200	400	1000	2000	3000	5000
Power Generation(kW.h/ 1m'Hz)	103	1.3	1.3	1.3	1.3	1.3
AC Output	220V AC/0.9A	220V AC/1.8A	220V AC/4.5A	220V AC/9.2A	/	220V AC/22.7A
DC Output	/	/	/	12V/10A 5V3A	48V/63A	/
Hydrogen Consumption(L/min)	≤3	≤5	≤12	≤25	≤35	≤60
(Fuel)	Hz，0.05/0.2MPa，99.99%
Energy Conversion Efficiency	40%~60%
Cooling Method	Air-cooled
Noise Level	＜60dB			＜65dB

FAQ:

1. Do I need to clean it regularly, just like cleaning my computer?

The battery fan has a fast speed and is not easy to accumulate dust. No special maintenance is required within the effective lifespan. Please keep the air outlet unobstructed.

2. Should I be worried about hydrogen leakage?

The battery structure itself is fixed with fasteners, end plates, frame structures, etc., without any leakage issues. But there will be a very small amount of unreacted hydrogen gas discharged from

the exhaust port. Even if you place the battery system completely indoors, as long as you don't fully lock the doors and windows, there won't be any safety issues.

3. How does the system perform at non-stop temperature?

The system has the best performance at an ambient temperature of 20 to 30℃. High or too low ambient temperature may affect the water and thermal balance of the system, especially when the ambient temperature is too low, and additional heating measures may be required to ensure the normal operation of the system

4. How reliable and is the durability of the system?

The reliability and durability of the air-cooled fuel cell system depend on the material quality, manufacturing process, system design and use conditions of the fuel cell. High quality fuel cell system has high reliability and durability, can meet the needs of long time stable operation.

the system includes:

The product includes: (customized) KW fuel cell (including fan), fuel cell dedicated DC, lithium battery (communication version), 7-inch display and control screen, motherboard, solenoid valve,

temperature sensor, high voltage sensor, low voltage sensor, ambient temperature transmitter, hydrogen leakage sensor, fan power supply DC, (corresponding to your customized) V DC,

(customized) A plug, stack output plug, silicone wire, off grid inverter, button switch, intake pressure display, relay, customized enclosure

Power:can be customzied

Various brands available

Supports all modes of transportation.

If there is a problem with the product, we will respond within 24 hours and provide compensation based on the specific situation.
